OVERVIEW


Supported by vast styling and luxurious level of comfort, the TMAX commands a dynamic presence while cruising on the busy city streets or long distance travelling. Equipped in an All-New 562cc engine accompanied by its lightweight chassis for smoother navigation, this sport scooter truly is Luxury in Motion.


Untitled (1920 × 200px).png


COLOR OPTION

68.png  TECH KAMO69.png  POWER GREY

FEATURES

POWERFUL 562CC ENGINE

WITH EURO5 COMPLIANT


The TMAX 560 harnesses the power of the 562cc, 2-cylinder engine to produce breathtaking torque and acceleration. Along with Yamaha Chip Controlled Throttle (YCC-T) system, it can give a smooth and controlled power delivery for such a high revving, high performance engine.



CRUISE CONTROL

FOR COMFORT


Considerably equip for long distance riding-and for added comfort and enjoyment, the Cruise Control system enhances the touring experience.



MONOTONE TFT

INSTRUMENT PANEL


The TMAX 560 equipped with a high-quality monochrome TFT multi-function instrument panel which incorporate a speedometer on the left and a tachometer on the right – while the central displays various indicators including fuel consumption, D-MODE, ABS and TCS.


EXQUISITE

BODY DESIGN


Equipped with a new compact LED 3-buld turn signal and a specially designed ‘boomerang’ side sections to give a more dynamic and modern appearance.



LIGHTWEIGHT

ALUMINIUM CHASIS


At the heart of the bike is a lightweight die-cast aluminium twin-spar frame, with optimized rigidity balance, that lets riders enjoy the full effect of the 562cc engine and CVT transmission.



Untitled (1920 × 200px).png


SPECIFICATION

Engine

Type
Liquid-cooled, 4-stroke, DOHC, 4-valves, In-Line
Cylinders
2 Cylinder
Displacement
562 cc
Bore x stroke
70.0 mm x 73.0 mm
Compression ratio
10.9:1
Maximum power
35.0 kW @ 7,500 rpm
Maximum torque
55.7 Nm @ 5,250 rpm
Lubrication System
Dry Sump
Fuel system
Fuel injection
Ignition system
TCI
Starter system
Electric

Transmission

Transmission system
V-Belt Automatic

Chasis

Overall length
2,200 mm
Overall width
765 mm
Overall height
1,420 mm
Seat height
800 mm
Wheelbase
1,575 mm
Minimum Ground Clearance
125 mm
Wet weight
220 kg
Fuel tank capacity
15.0 L

Brakes

Front brake
Hydraulic dual disc brake
Rear brake
Hydraulic single disc brake

Suspension

Front Suspension Type
Telescopic forks
Rear Suspension Type
Swingarm (link suspension)



Tires

Front Tyre
120/70R15M/C 56H Tubeless
Rear Tyre
160/60R15M/C 67H Tubeless
